Manual Unidirectional Knife Gate Valve

Manual Unidirectional Knife Gate Valve Product introduction

　Unidirectional Knife Gate Valve Manufacturer, China Unidirectional Knife Gate Valve Factory and Supplier. Manual Unidirectional Knife Gate Valve is wafer design valve. One piece cast body with guides to support gate and seat wedges. Provides high flow rates with low pressure drop and include various seat and packing materials available. Face to face dimension in accordance with our valves standard. An arrow is marked on the body indicating the flow direction. Manal Unidirectional Knife Gate Valve is suitable for liquids that contain a maximum of 5% suspended solids. Manual Unidirectional Knife Gate Valve is used for dry solids in gravity feed applications it should be installed with the arrow on the body pointing in the opposite direction to the flow.

Manual Unidirectional Knife Gate Valve Utilization

Designed for applications such as:

Paper Industry, Mining, Silo emptying, Chemical plants, Bumping Food, Industry Sewage treatment.

Manual Unidirectional Knife Gate ValveSizes

Standard manufacturing sizes: From DN50 up to DN1200

Manual Unidirectional Knife Gate Valve Working pressures

DN 50-250 = 10 bar
DN 300-400 = 6 bar
DN 450 = 5 bar
DN 500-600 = 4 bar
DN 700-1200 = 3 bar
