Electric motorized ceramic butterfly valve

Electric motorized ceramic butterfly valveElectric motorized ceramic butterfly valve
Electric motorized ceramic butterfly valve

Electric motorized ceramic butterfly valve Product introduction

 Electric motorized ceramic butterfly valve is composed of wafer or flanged end ceramic lined butterfly valve and electric actuator for automatic control. Electric motorized ceramic butterfly valve sealing part adopts ceramic structure material, and arched surface contact part is precision-machined ceramic. Electric motorized ceramic butterfly valve is eccentrically structured to reduce the fiction of motion part, and greatly extend valve service lifetime in use. The materials of ceramic lined butterfly valve’s ceramic sealing ring, O ring, butterfly disc can be replaced according to purpose and demand. Electric motorized ceramic butterfly valve is applicable to special operating conditions of strong abrasion, high temperature, and high corrosion.

Electric motorized ceramic butterfly valve specification
Nominal diameter: DN50~1000mm ( 2"~40")
Nominal pressure: PN1.0~4.0MPa(150~300Lb)
Applicable temperature:≤ 350℃
Material: carbon steel, stainless steel,etc.
Medium: ash residue, sludge residue, coal residue, ore pulp, waste water etc.
Application range: metallurgy, steel, mining, power, coal conveying plant, cement plant, water
treatment etc.

Electric motorized ceramic butterfly valve Related Products
