Q341F Q341Y Floating ball valve Product introduction
Q341F Q341Y Floating ball valve introduction:
Q341F Q341Y floating ball valve is 1PC 2PC 3PC soft seated structure with PTFE,RPTFE,Delvon,PEEK seat material, Q341F Q341Y floating ball valve is full bore bore,floating ball design, Q341F Q341Y floating ball valve is widely used in long-distance pipeline, oil refining, power, paper, chemical, pharmaceutical, steel, municipal, water and other industries, the oil pipeline in the area plays an important role. The main characteristics of Q341F Q341Y floating ball valve is reliable, compact, easy maintenance, simple structure, with the spherical sealing surface often in closed state, the media can not easily be eroded, easy operation and maintenance for natural gas, solvents, water, acid and other general working medium.
Q341F Q341Y Floating ball valve Specification:
| Product Name |
Q341F Q341Y Floating ball valve |
| 1. Material |
SS304/316/304L/316L ( CF8/CF8M/CF3/CF3M), WCB, etc. |
| 2. Size |
1/2~12 inch ( DN15~DN300) |
| 3. Port |
Full Port |
| 4. Working Pressure |
150LB~600LB |
| 5. Connection Ends |
Flange |
| 6. Working Temp. |
-20~180ºC, or according to customer requirements for different industry. |
| 7. Suitable Medium |
Water, Natural Gas, Oil and some corrosive liquid |
| 8. Operation |
Handle operated, Locking device is option |
| 9. Inspection & Testing |
According to API598 |
Q341F Q341Y Floating ball valve Technical Specification:
1. Design & Manufacture standard: API 6D, API 608, BS 5351.
2. Pressure & Temperature standard: ASME B16.34.
3. Face to face dimension standard: ASME B16.10.
4. Flange standard: ASME B16.5, ASME B16.47.
5. Test & Inspect standard: API 598, API 6D.
Q341F Q341Y Floating ball valve Product Feature:
1. Floating ball, full bore or reduce bore.
2. ISO5211 mounting pad for option.
3. Blow-out proof stem design.
4. PTFE/RPTFE/Delvon/PEEK seat seal( Seat seal material could be decided by customer's request or according to valve's medium & temp. Condition).
5. Fire-proof and anti-static design if need.
6. Operation: Hand wheel, Worm wheel, Pneumatic actuator & Electric Actuator.
