Stainless steel ball valve 4 inch

Stainless steel ball valve 4 inch Product introduction

　Stainless steel ball valve 4 inch is used for water, steam, oil, nitric acid, acetic acid, oxidizing medium, urea and other medium.Stainless steel ball valve 4 inch can be widely used in papermaking, petrochemical, chemical industry, metallurgy, electric power, environmental protection, petroleum, light industry and other industrial departments of automatic control system.

Stainless steel ball valve 4 inch Specification:

Product Name	Stainless steel ball valve 4 inch
1. Material	WCB 304 316 CF8 CF8M or others
2. Size	1/2~12 inch ( DN15~DN300)
3. Port	Full Port or reduced port
4. Working Pressure	150LB~600LB
5. Connection Ends	Flange or others
6. Working Temp.	-29～150℃,-40～450℃, or according to customer requirements for different industry.
7. Suitable Medium	Water, Natural Gas, Oil and some corrosive liquid
8. Operation	Handle operated, Locking device is option
9. Inspection & Testing	According to API598

Stainless steel ball valve 4 inch Technical Specification:
1. Design & Manufacture standard: API 6D, API 608, BS 5351.
2. Pressure & Temperature standard: ASME B16.34.
3. Face to face dimension standard: ASME B16.10.
4. Flange standard: ASME B16.5, ASME B16.47.
5. Test & Inspect standard: API 598, API 6D.

Stainless steel ball valve 4 inch performance:
1. Floating ball, full bore or reduce bore.
2. ISO5211 mounting pad for option.
3. Blow-out proof stem design.
4. PTFE/RPTFE seat seal( Seat seal material could be decided by customer's request or according to valve's medium & temp. Condition).
5. Fire-proof and anti-static design if need.
6. Operation: Hand wheel, Worm wheel, Pneumatic actuator & Electric Actuator.
