China 1000 WOG ball valve

China 1000 WOG  ball valveChina 1000 WOG  ball valve
China 1000 WOG ball valve

China 1000 WOG ball valve Product introduction

 China 1000 WOG ball valve manufacturer, factory and supplier. 1000 WOG ball valve can be threaded end, welded end with 1pc, 2pc or 3pc body according to client's need.1000 WOG ball valve is used in sanitary, corrosive, or industrial applications where brass ball valves are not suitable. 1000 WOG ball valve has blow-out proof stems with a 304 SS 316SS body and ball and a 304SS pad-lockable handle. 1000 WOG ball valve is suitable for 1000 psi (at ambient temperature) water, oil, or gas and steam.

China 1000 WOG ball valve Specification
Type: Ball Valve, 1, 2 or 3-Piece, Full Port
Size: 3/8"-4''
Rating: 1000 WOG (Other pressure class is optional)
Connection: Threaded (NPT,BSP,RC) or welded end (SW,BW)
Body Material: WCB, 304SS 316SS or other material
Ball: WCB, 304SS 316SS or other material
Stem: 304SS 316SS or other material
Seats: PTFE
Minimal pressure drop due to large full size ports
Suitable for full range of liquids and gas
Temperature range : -40 to 400 degree Fahrenheit
Low operation torque
Blowout-proof stem
FxF NPT Threaded ends to ANSI B1.20.1
Heavy duty locking handles
ISO 5211 mounting pad for lever, electric or pneumatic actuator
