NPT Screwed 3000 PSI ball valve

NPT Screwed 3000 PSI ball valveNPT Screwed 3000 PSI ball valve
NPT Screwed 3000 PSI ball valve

NPT Screwed 3000 PSI ball valve Product introduction

 China 3000 PSI ball valve manufacturer, factory and supplier. NPT Screwed 3000 PSI ball valve is NPT,BSP,RC threaded end with WCB, 304SS, 316SS or other material is optional. NPT Screwed 3000 PSI ball valve can be used in sanitary, corrosive, or industrial applications for (at ambient temperature) water, oil, or gas and steam. NPT Screwed 3000 PSI ball valve has blow-out proof stems with a WCB 304 SS 316SS body and ball and a 304SS pad-lockable handle. ISO 5211 mounting pad is optional for lever, electric or pneumatic actuator.

NPT Screwed 3000 PSI ball valve specification
Type: Ball Valve, 2 piece or 3 piece, Full Port
Size: 3/8"-2''
Rating: 3000 WOG,3000 PSI (Other pressure class is optional)
Connection: Threaded (NPT,BSP,RC) or welded end (SW,BW)
Body Material: WCB, 304SS 316SS or other material
Ball: WCB, 304SS 316SS or other material
Stem: 304SS 316SS or other material
Seats: PTFE
Minimal pressure drop due to large full size ports
Suitable for full range of liquids and gas
Temperature range : -40 to 400 degree Fahrenheit
Low operation torque
Blowout-proof stem
FxF NPT Threaded ends to ANSI B1.20.1
Heavy duty locking handles
ISO 5211 mounting pad for lever, electric or pneumatic actuator
